Networked Digitizer

D-TACQ digitizers can plug in directly to the plant Ethernet.

  • Lowest cost deployment, self supporting unit needs only a chassis and network cable.
  • Small-formfactor ACQ1001 units are networked DAQ appliances running from 4 .. 64 channels.
  • ACQ2006 19" wide 1U DAQ appliance with up to 192 simultaneous channels.
  • Network digitizers are cost effective for "small" systems with a single card.
    With ACQ196CPCI, a "small" system has 32 .. 96 channels.
  • Uses standard TCP/IP networking.
  • Control from remote computer, simple, open standards, "no device driver required"
  • Data upload to remote computer, multiple methods available.
    The remote computer is typically a server-class PC with a high performance disk sub-system.
  • Highly scaleable - simply add more cards and more network cards, at upload time, all the cards can work in parallel.

Example: ACQ1001Q appliance


ACQ1001Q+ACQ420 : 4 channel DAQ appliance


Example: ACQ2006 appliance


ACQ2006, 6 site DAQ appliance to 192 channels


Example: 4 x ACQ196CPCI 384 channels in 2U


4 x ACQ196CPCI, 384 channels in 2U
